Curing Lamp
|
|
|
| |
|
|
|
|
| |
Single Lamp Infra-Red Paint Curing Unit |
|
|
| |
|
|
|
|
| |
 |
Model Number: 602021 |
|
|
| |
|
|
|
| |
- Simple infra-red curing lamp with 30 min. timer
- Ruby sleeve to reduce glare
|
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
|
|
| |
Documents: |
Specifications
|
| Model Number |
602021 |
| Curing area |
23.6" x 15.7" |
| Minimum distance |
15.75" |
| Power rating |
1 x 1,000 watts |
| Power supply |
220 Volts AC |
| Temperature |
140 x 158 F |
| Stand height |
55" |
| Low working height |
15.75" |
|
|
| |
|
|
| |
Literature |
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
|
|
| |
|
|
|
|
| |
|
|
|
|
| |
Twin head Infra-Red Paint Curing Unit |
|
|
| |
|
|
|
|
| |
|
 |
Model Number: 602022 |
|
|
| |
|
|
|
|
| |
|
- Infra-red paint curing lamps with electronic controller
- Precise curing timer and power adjuster
- Audible alarm when curing process is finished
- Gas strut arm support
- 300 degree swivel
- Touch button controls
- Emitter with ruby sleeve to reduce glare
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
|
|
|
| |
|
Documents: |
Specifications
|
| Model Number |
602022 |
| Curing area |
23.6" x 31.5" |
| Minimum distance |
15.75" |
| Temperature |
140 - 158F |
| Power rating |
2 x 1,000 watts |
| Power supply |
220 Volts AC |
| Stand height |
64.5" |
|
|
| |
|
|
|
| |
|
Literature |
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
|
|
| |
|
|
|
|
|
| |
|
|
|
|
|
| |
|
Three Head Infra-Red Paint Curing Unit |
|
|
| |
|
|
|
|
|
| |
|
 |
Model Number: 602023 |
|
|
| |
|
|
|
|
| |
|
- Infra-red paint curing lamps with electronic controller
- Precise curing timer and power adjuster
- Adjustable heads to position the emitters over panel
- Swivels 300 degrees
- Touch button controls
- Super low profile rolling legs
- locking pneumatic control positioning arm
- Audible alarm when curing process is finished
- Emitter with ruby sleeve to reduce glare
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
|
|
|
| |
|
Documents: |
Specifications
|
| Model Number |
602023 |
| Curing area |
39.3" x 31.5" |
| Minimum distance |
15.75" |
| Power rating |
3 x 1,000 watts |
| Curing area |
39.3" x 31.5" |
| Temperature |
140 - 158F |
| Stand height |
64.5" |
| Power supply |
220 Volts AC |
|
|
| |
|
|
|
| |
|
Literature |
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
|
|
| |
|
|
|
|
|
| |
|
